| Product Name |
|
| PORTABLE CUTTING MACHINES >>> BEAVER - 5602030 |
| Description |
|
|
|
|
 Properties
With an optional auto-stop function, the operator does not need
any more to watch the rail ending point
On straight line cutting, the longer the distance, the better
the running stability! While on curved line cutting, the shorter
the distance.
BEAVER resolves the problem by shifting the guide wheel and succeeds
in getting both running stability of straight line cutting and tracing
accuracy of curved line cutting
When BEAVER is not operated, it can be stored with its grip upward.
Therefore BEAVER saves the space to keep it, and makes it easy to
clean the tip.
Simple body for easy maintenance
|
|
|
| Files : |
|
|
| Applications : |
|
BEAVER is a portable automatic gas-cutting
machine of a unique structure, which wins success in two different functions
- that is running stability of straight line cutting and tracing accuracy
of curved line cutting
|
|
| Cutting thickness |
3-30 mm |
| Cutting speed |
50~1000 mm |
| Circle cutting radius (with
optional equipment) |
30~350 mm |
| Cutting shape |
I.V. |
| Speed change |
Variable register |
| Power |
42VAC, 110 VAC veya 220 VAC |
| Machine length |
430mm |
| Weight |
9kg |
|
|
| Power Cable |
|
5m |
| Tip 102 (for acetylen) #0,
1, 2 or 106 (for LPG) |
|
1 adet |
| Tip cleaner set |
|
1 pc each |
| Lighter |
|
1 |
| Tool set |
|
1 |
| Hose (from valve to torch)
|
|
3 |
|
|
|
| Auto stop device (switch and magnetic block)
|
|
| Circle cutting device |
|
| Spare parts kit |
|
| Straight rail 1,8 mtr |
|
|
|
|
|
|
