Hypertherm Plasma Cutting Machine
|
|
|
 Properties
Superior speed and capacity
Longer parts life
Lower operating cost
Higher-quality cuts
Safety and Reliability and Ease of use
High duty cycle permits industrial cutting
Advanced digitally-controlled inverter design improves cut
quality by delivering constant output regardless of variations
in line voltages or torch-to-work distances
An active electronic pilot arc controller for cutting expanded
metal or grating
An architecture that tolerates power fluctuation and surges
|
|
|
| Files : |
|
|
| Applications : |
|
It is an inverter type plasma cutting
machine which cuts metals to 3/8' (10 mm) at cutting speed 25' (640
mm) per minute, metals to 5/8' (16 mm) at cutting speeds over 9'
(240 mm) per minute and which has a severance capacity of 7/8' (22
mm)
|
|
| Input Voltages |
200-600 V / 50-60 Hz |
| Input Current 1PH/3PH |
40/9,7 A |
| Output Voltage |
140 VDC |
| Output Current |
20-40 A (Ayarlanabilir) |
| Maximum OCV |
300 VDC |
| Dimensions (DxWxH) |
|
| Weight with Torch |
21 kg |
|
|
| Plasma Gas |
Air or Nitrogen |
| Shield Gas |
Air or Nitrogen |
| Flow Rate (Plasma Gas) |
170 l/min |
| Flow Rate (Shield Gas) |
170 l/min |
| Flow Pressure (Plasma
Gas) |
5.0 bar |
| Flow Pressure (Shield
Gas) |
5.0 bar |
|
|
