| Product Name |
|
| WELDING RECTIFIERS >>> GL 451 |
| Description |
|
|
|
|
|
Mechanically Controlled Welding Rectifier
|
|
|
 Properties
Heavy duty welding machine .
Especially for outdoor use.
Ideal weldin characteristics for all type of electrodes.
Carbon gouging up to 8 mm.
-
Easy and low cost maintenence & repair.
|
|
|
| Files : |
|
|
| Line Voltage (3 Phase) |
380 V / 50 Hz |
| Input Power (40%) |
35 KVA |
| Input Current (40%) |
53 A |
| Recommended Line Fuses |
3 x 63 A |
| Rated Welding Current
(40%) |
450 ADC |
| Welding Current Range |
60 - 550 ADC |
| Open Circuit Voltage |
73 VDC |
| - |
|
| Dimensions ( l x w x h ) |
820 x 518 x 900 mm |
| Weight |
232 kg |
| Protection Class |
IP 22 |
| - |
|
| Line Cables |
4 x 6 mm2 - 5 mt |
|
|
| Electrode holder (70mm2 - 5m) |
|
|
| Work Clamp (70mm2 -
3m) |
|
|
|
|
|
|
