400 Amp. Engine Driven Welder
|
|
|
 Properties
DAS, engine protection shutdown system for; battery charger failure,
low fuel level, low oil level & pressure.
Built-in battery for automatic start-up
-
Three phase 400V / 50 Hz outlet.
Single phase 230 V / 50 Hz outlet protected by circuit braker.
Single phase 48V / 50 Hz outlet (5 KVA)
Voltmeter.
Hourmeter.
Fuel level gauge.
ELCB protection.
Automatic idling device.
Remote control socket.
ARC FORCE device.
-
Central lifting hook,
GRT 2WD, Two wheels site trailer with towing bar.
|
|
|
| Files |
|
|
| Application : |
|
This engine driven welder is designed and
built with heavy-duty industrial components to allow it to operate in
remote locations without downtime. Best results are obtained with all
types of electrodes including cellilosic electrodes. Carbon gouging is
up to 8 mm. This machine is an ideal choice for the costruction and repair
of pipe-lines, highways, railroads, telecomunication towers and any other
rural area applications.
|
|
| Type |
Ruggerini RD 270 Diesel |
| Power |
27 HP |
| Displacement |
1205 cm3 |
| Cylinders |
2 |
| Speed |
3000 / dk |
| Cooling |
Air |
| Starter |
Electric |
| Fuel |
Diesel |
| Specific Consumption |
250 gr/KWh |
| Fuel Tank Capacity |
38 lt |
|
|
| TYPE |
Gen Set Asynchrounous Brushless
|
| 3 Phase Power |
10 KVA - 400 V |
| 1 Phase Power |
8 KVA - 230 V |
|
|
| Maximum Welding Current |
400 ADC - 36 VDC |
| Rated Welding Current (60%) |
300 ADC - 32 VDC |
| Welding Current Range |
30 - 400 ADC |
| Open Circuit Voltage |
70 VDC |
|
|
| Dimensions ( l x w x h ) |
1300 x 620 x 810 mm |
| Weight |
395 kg |
| Noise Level ( Lwa ) |
99 |
|
|
|
| Electrode Holder and 20 mt
Welding Cable (50 mm2) |
|
| Work Clamp and 15 mt Welding Cable (50
mm2) |
|
| Remote Control Kit |
|
| Parallel Welding Box with
Voltmeter / Ammeter |
|
|
|
|
